- Input DC Voltage : 12~24VDC (28V Max)
- Input DC Current : 12VDC 6A (8A Max) / 24VDC 6A (8A Max)
- Output PoE DC Voltage : 48VDC (56VDC Max)
- Output DC Current & Watts : 0.62A Max / 30W Max
- 12VDC Input, 4 Port Output :
- 15W+15W+15W+15W or 30W+15W+7W+7W
- 24VDC Input, 4 Port Output : 30W+30W+30W+30W
- Support Each Ethernet Bandwidth :10/100/1000Mbps (1Gbps) Bandwidth
- Ethernet Cable SPEC : Cate 5 ~ 5e support 100Mbps, Cate 6 ~ support 1Gbps
- Compatible with IEEE802.3 / 802.3u / 802.3af / 802.3at PoE Standard
- Transform Efficiency : 90%
- Operating Temperature : -40°C ~ +80°C
- Dust & Waterproof Rate : IP67
|
